Fluke 710 Milliamp Loop Valve Tester, 0 to 24mA, 0 to 30V is a product engineered with precision, delivering exceptional performance
with features like key valve testing functions include preconfigured valve signature test speed test step test manual test and bumppartial stroke test, key mA loop calibrator functions include mA source mA simulate mA read mA readloop power and volts read and valveTrackª Software enables upload to a PC for further indepth analysis of valve measurements that are logged and recorded to memory.
Maintive brings to you 100% genuine Loop Calibrators from Fluke at your doorstep with fast shipping, multiple and secure payment methods and easy returns. Order 710 Milliamp Loop Valve Tester, 0 to 24mA, 0 to 30V today at the best price only from Maintive.
Features
Key valve testing functions include pre-configured valve signature test, speed test, step test, manual test, and bump/partial stroke test
Key mA loop calibrator functions include mA source, mA simulate, mA read, mA read/loop power, and volts read
ValveTrackª Software enables upload to a PC for further in-depth analysis of valve measurements that are logged and recorded to memory
Manual testing; manually change the mA signal and view the HART position and pressure variable information
Full range ramping of the mA signal from 4 to 20 to 4 mA while recording the 0-100-0% position, or the pressures applied that move the valve from 0-100-0%
Stepping the mA signal on the input to the valve in steps and evaluating the valves response to the mA input changes
Speed tests to determine how fast the valve can open or close
Bump and partial stroke tests that help test valves over a portion of their range so they can be tested in a live process
Items Included
Stackable test lead set
Extended tooth alligator clip set
TP220 test probes
AC280 SureGrip™ hook clips
Lemo to USB upload/download cable
ValveTrack™ software (free download)
Softcase
Six AAA batteries (installed)
709/709H/710 Product manual CD-ROM
709/709H/710 Quick reference guide
709/709H/710 Safety information
Specifications
FunctionsmA source, mA simulate, mA read, mA read/loop power, and volts read.
Current MeasurementmA (0 to 24 mA)
Voltage Measurement0 to 30 V DC
Resolution1 µA on mA ranges and 1 mV on voltage range
Accuracy0.01% ± 2 counts
Operating temperature range-10°C to 55°C (14°F to 131°F)
Humidity range10 to 95% non-condensing
Stability20 ppm of F.S. /°C from -10°C to 18°C and 28°C to 55°C
Display128 x 64 pixels, LCD Graphic w/backlight, .34 high digits
Dimensions (L x W x D)15 x 9 x 3 cm (6 x 3.6 x 1.3 in)
Warranty3 years manufacturer's warranty
FunctionsmA source, mA simulate, mA read, mA read/loop power, and volts read.
Current MeasurementmA (0 to 24 mA)
Voltage Measurement0 to 30 V DC
Resolution1 µA on mA ranges and 1 mV on voltage range
Accuracy0.01% ± 2 counts
Operating temperature range-10°C to 55°C (14°F to 131°F)
Humidity range10 to 95% non-condensing
Stability20 ppm of F.S. /°C from -10°C to 18°C and 28°C to 55°C
Display128 x 64 pixels, LCD Graphic w/backlight, .34 high digits
Dimensions (L x W x D)15 x 9 x 3 cm (6 x 3.6 x 1.3 in)
