Pressure Test Gauge, -12 to 500 PSI, 34 Bar

Model # 700G07
AED 4,253.00Incl. of VAT
AED 4,725.0010% Off
Limited Stock
Use Coupon Code: WELCOME25
This item is eligible for return.
Delivery
Friday, Jun 2
FREE
Click & Collect
Today, 9:00 AM - 4:30 PM
FREE

Features

  • Bright backlit display for easy viewing of pressure measurements
  • Rugged; durable design with protective holster
  • High accuracy; 0.05% total measurement uncertainty for one year
  • Combined with either the 700PTPK pneumatic pump kit or the 700HTPK hydraulic pump kit for a complete measurement and testing solution
  • Rugged design with intrinsically safe certification
  • Standard accuracy to 0.05% of full scale
  • Allows you to work safely in classified areas known to include explosive gasses
  • Easily view in most environments with bright backlit display
  • Make precise pressure measurements from ±10 inH2O/20 mbar to 10,000 psi/690 bar

Items Included

  • Fluke 700G07 Pressure Test Gauge, 500 psig

Specifications

  • Range-12 to 500 psi, -0.83 to 34 bar
  • Resolution0.01 psi, 0.001 bar
  • AccuracyPositive pressure ± 0.05 % FS Vacuum ± 0.1 % FS
  • Burst Pressure2000 psi, 138 bar
  • Dimensions (HxWxD)12.7 cm x 11.4 cm x 3.7 cm (5 in x 4.5 in x 1.5 in)
  • Pressure connection1/4 in NPT Male, ( 1/4 in NPT to 1/4 ISO adapter provided)
  • Weight0.56 kg, 1.22 lbs with holster
  • Display5-1/2 digits, 16.53 mm (0.65 in) high 20 –segment ar graph, 0 to 100 %
  • Battery life1,500 hours without backlight (continuous on), 2,000 hours at slow sample rate
  • Warranty3 years manufacturer's warranty
