Small rugged design operates on (6) standard AAA batteries
Intuitive user interface with Quick-Set knob for fast setup; easy use
Built in selectable 250 resistor for HART communication
Fast transfer of calibration data:The optional 709H/Track software/cable can document the parameters of all the HART transmitters in your plant, in either (.csv) or (.txt) format
Provides resolution of 1 µA on mA ranges and 1 mV on voltage ranges
Quickly transfers calibration data for documentation in either (.csv) or (.txt) format with optional 709H/Track software/cable
Offers selectable capture interval from 1 to 60 seconds and a logging capacity of 9800 records or 99 individual sessions.
Requires only simple two wire connection for all measurements
Items Included
754-8016 Alligator Clip Set
75X-8014 Stackable Lead Set
TP220-4201 Test Probes
AC280-5001 SureGrip Hook Clips
Soft Case
Six AAA Batteries (Installed)
Product Manual CD-ROM
Quick Reference Guide
Safety Information
Specifications
FunctionsmA source, mA simulate, mA read, mA read/loop power, and volts read.
Current Measurement0 to 24 mA
Voltage Measurement0 to 30V
Resolution1 µA on mA ranges and 1 mV on voltage range
Accuracy0.01% ± 2 counts, all ranges (@23° ± 5°C)
Operating temperature-10°C to 55°C (14°F to 131°F)
Stability20 ppm of F.S. /°C from -10°C to 18°C and 28°C to 55°C
Display128 x 64 pixels, LCD Graphic w/backlight, .34 high digits
Dimensions15 x 9 x 3 cm (6 x 3.6 x 1.3 in)
Loop compliance voltage24 V DC @ 20mA
Warranty3 years manufacturer's warranty
FunctionsmA source, mA simulate, mA read, mA read/loop power, and volts read.
Current Measurement0 to 24 mA
Voltage Measurement0 to 30V
Resolution1 µA on mA ranges and 1 mV on voltage range
Accuracy0.01% ± 2 counts, all ranges (@23° ± 5°C)
Operating temperature-10°C to 55°C (14°F to 131°F)
Stability20 ppm of F.S. /°C from -10°C to 18°C and 28°C to 55°C
Display128 x 64 pixels, LCD Graphic w/backlight, .34 high digits
Dimensions15 x 9 x 3 cm (6 x 3.6 x 1.3 in)
Loop compliance voltage24 V DC @ 20mA
Warranty3 years manufacturer's warranty
