Fluke 717-15G Pressure Calibrator 15 PSIG, 1 Bar is a product engineered with precision, delivering exceptional performance
with features like measure pressure and vacuum to 005 of full scale with the internal 15 psig sensor 15G Model, 18 NPT pressure fitting and compatible with noncorrosive gasses and liquids.
Maintive brings to you 100% genuine Pressure Calibrators from Fluke at your doorstep with fast shipping, multiple and secure payment methods and easy returns. Order 717-15G Pressure Calibrator 15 PSIG, 1 Bar today at the best price only from Maintive.
Features
Measure pressure and vacuum to 0.05% of full scale with the internal 15 psig sensor (15G Model)
1/8 NPT pressure fitting
Compatible with non-corrosive gasses and liquids
Measure pressure -85 to 103 kPa using one of the Fluke 750 Series Pressure Modules
Measure pressure to 10,000 psi/700 bar using one of 29 Fluke 700Pxx Pressure Modules
Measure pressure, 0.05% of full scale with internal sensor up to 5000 PSI/345 bar sensor (5000G model)
Measure mA with 0.015% accuracy and 0.001 mA resolution, while sourcing 24V loop power
Select eleven different engineering units
Zero, min, max, and hold functions
Items Included
Protective Yellow Holster with test lead storage
Instructions Sheet (14 languages)
Single 9V alkaline battery
Test Leads and Alligator Clips
NIST- traceable calibration report and data
Specifications
Range29 pressure modules, 0 – 1 in H20 to 10,000 PSI, 2.5 mbar to 700 bar ranges over pressure per pressure module specs
ResolutionPer pressure module specs
Accuracy0.025 % of full span, per pressure module specs
