Manual Vibration Tester, 0 to 80g Peak, 2 to 20,000Hz

Model # 810
AED 48,195.00Incl. of VAT
AED 53,550.0010% Off
Use Coupon Code: WELCOME25
This item is eligible for return.
Orders over AED 99 ship free in the UAE.
Want to know when it's back in stock?


  • On-board identification and location of the most common mechanical faults (bearings; misalignment; unbalance; looseness) focus maintenance efforts on root cause; reducing unplanned downtime
  • Overall vibration level allows you to quickly assess overall machine health directly from the diagnosis screen
  • Fault severity scale with four severity levels helps you prioritize maintenance work
  • Repair recommendations advise technicians on corrective action
  • Detailed diagnostic reports and spectral diagrams help confirm data quality, and narrow down the root cause of failures
  • On-board context sensitive help provides real-time tips and guidance to new users
  • Flexible machine speed configurations gives the ability to test a broad range of assets including belt drives, gear boxes, and bevel gears
  • 2 GB expandable on-board memory provides enough space for your machinery’s data
  • Self-test function ensures optimal performance and more time on the job

Items Included

  • Vibration Tester with diagnostic technology
  • Tri-axial accelerometer
  • magnet mount
  • mounting pad kit with adhesive
  • accelerometer quick-disconnect cable
  • Laser tachometer and storage pouch
  • Smart battery pack with cable and adapters
  • Shoulder strap and adjustable hand strap
  • Viewer PC software
  • Mini USB to USB cable
  • Getting Started Guide
  • illustrated quick reference guide
  • Users Manual CD-ROM
  • Carrying case


  • Standard FaultsUnbalance, looseness, misalignment and bearing failures
  • Analysis ForMotors, fans, blowers, belts and chain drives, gearboxes, couplings, centrifugal pumps, piston pumps, sliding vane pumps, propeller pumps, screw pumps, rotary thread/gear/lobe pumps, piston compressors, centrifugal compressors, screw compressors, closed coupled machines, spindles
  • Motor Rotational Speed Range200 rpm to 12000 rpm
  • A/D Converter4 channel, 24 bit
  • Usable Bandwidth2 Hz to 20 kHz
  • Sampling51.2 Hz
  • Sampling Rate2.5 kHz to 50 kHz
  • Dynamic Range128 dB
  • Signal To Noise Ratio100 dB
  • FFT Resolution800 lines
  • Dimensions (H x D x W)18.56 x 7.00 x 26.72 cm (7.30 x 2.76 x 10.52 inches)
  • Display¼ VGA, 320 × 240 Color (5.7 inch diagonal) TFT LCD with LED backlight
  • Input ConnectionsTriaxial sensor connection: 4 pin M12 connector
  • AC AdapterInput voltage: 100 VAC to 240 VAC Input frequency: 50/60 Hz
  • Operating Temperature0°C to 50°C (32°F to 122°F)
  • Storage Temperature-20°C to 60°C (-4°F to 140°F)
  • Operating Humidity10% to 95% RH (non-condensing)
  • Warranty3 years manufacturer's warranty
