CAT IV 600 V; Cat III 690 V safety rating Fluke’s family of Two-Pole Voltage testers comply with both regulation HSE GS 38 (tip caps) and IEC EN 61243-3: 2010.
4 ways to detect ac/dc voltage A clear; instantly visible LED indicator; a bright digital display of the measurement value; an audible continuity test; and vibration to give tactile feedback
Audio on/off for testing in quiet areas.
Low battery indicator
Dual insulated cable tested to 3x the required bend angle provides increased reliability and durability
Switchable load: avoid display of ghost voltages allowing you to draw more current from the circuit under test and avoid trip residual-current devices (RCDs)
Backlit graduated scale and backlit indicators
Phase rotation indicator for 3-phase systems
Built in electric torch for use in dark areas
Items Included
Voltage/Continuity Tester With LCD Ohms Switchable Load
Specifications
Voltage6V - 690V
Continuity0 - 400 k
Frequency0 / 40 - 400 Hz
Phase rotation100 V - 690 V
Response Time (LED indicator)< 0.5 s
Input impedance200 kΩ- Current draw 3,5 mA @ 690 V Current draw 1,15 mA @ 230 V
Input impedance7k - Current draw 30 mA @ 230 V
IP ratingIP64
Size23 cm x 6.5 cm x 3.8 cm
Warranty2 years manufacturer's warranty
Voltage6V - 690V
Continuity0 - 400 k
Frequency0 / 40 - 400 Hz
Phase rotation100 V - 690 V
Response Time (LED indicator)< 0.5 s
Input impedance200 kΩ- Current draw 3,5 mA @ 690 V Current draw 1,15 mA @ 230 V
Input impedance7k - Current draw 30 mA @ 230 V
IP ratingIP64
Size23 cm x 6.5 cm x 3.8 cm
Warranty2 years manufacturer's warranty
