Fluke TiX501 9Hz Thermal Imaging Camera, 640x480, 9Hz, -20 to +650 °C is a product engineered with precision, delivering exceptional performance
with features like shoot images near and far Interchangeable Smart Lenses require no calibration of the thermal camera and give you the versatility and image quality needed to conduct inspections in almost any environment, find subtle temperature differences easilywith advanced thermal sensitivity and subject to Export Control.
Maintive brings to you 100% genuine Thermal Cameras from Fluke at your doorstep with fast shipping, multiple and secure payment methods and easy returns. Order TiX501 9Hz Thermal Imaging Camera, 640x480, 9Hz, -20 to +650 °C today at the best price only from Maintive.
Features
Shoot images near... and far. Interchangeable Smart Lenses require no calibration of the thermal camera and give you the versatility and image quality needed to conduct inspections in almost any environment.
Find subtle temperature differences easily-with advanced thermal sensitivity
Subject to Export Control
Edit and optimize images
Combine infrared and visible images for simpler analysis
Create detailed reports
Items Included
1x Thermal imager with standard infrared lens
1x AC power supply and battery pack charger
2x Rugged lithium ion smart battery packs
1x USB cable
1x HDMI video cable
1x Rugged, hard carrying case
1x Soft transport bag
1x Adjustable hand and neck strap
Specifications
IFOV (Spatial Resolution)0.93 mRad, D:S 1065:1
Infrared resolution640 x 480 (307,200 pixels)
Field of view34 °H x 24 °V
Minimum focus distance15 cm (approx. 6 Inches)
Thermal sensitivity (NETD)≤0.075 °C at 30 °C target temp (75 mK)
Frame rate60 Hz or 9 Hz versions
Temperature-20 °C to +650 °C
Color alarms (temperature alarms)High temperature, low temperature, and isotherms (within range)
Infrared spectral band7.5 μm to 14 μm (long wave)
Operating temperature-10 °C to +50 °C (+14 °F to +122 °F)
Storage temperature-20 °C to +50 °C (-4 °F to +122 °F) without batteries
Relative humidity10 % to 95 % non-condensing
Vibration0.03 g2/Hz (3.8 g), 2.5 g IEC 60068-2-6
Shock25 g, IEC 68-2-29
Size (H x W x L)27.3 x 15.9 x 9.7 cm (10.8 x 6.3 x 3.8 inches)
IFOV (Spatial Resolution)0.93 mRad, D:S 1065:1
Infrared resolution640 x 480 (307,200 pixels)
Field of view34 °H x 24 °V
Minimum focus distance15 cm (approx. 6 Inches)
Thermal sensitivity (NETD)≤0.075 °C at 30 °C target temp (75 mK)
Frame rate60 Hz or 9 Hz versions
Temperature-20 °C to +650 °C
Color alarms (temperature alarms)High temperature, low temperature, and isotherms (within range)
Infrared spectral band7.5 μm to 14 μm (long wave)
Operating temperature-10 °C to +50 °C (+14 °F to +122 °F)
Storage temperature-20 °C to +50 °C (-4 °F to +122 °F) without batteries
Relative humidity10 % to 95 % non-condensing
Vibration0.03 g2/Hz (3.8 g), 2.5 g IEC 60068-2-6
Shock25 g, IEC 68-2-29
Size (H x W x L)27.3 x 15.9 x 9.7 cm (10.8 x 6.3 x 3.8 inches)
